| Pluto SDR | Pluto+ | LibreSDR ZYNQ | 7010 AD9363 SDR Mini | New 7020-SDR without Amplifier | New 7020-SDR with amplifier | GeekRF One | PCIE Version PlutoSDR AD9363 XC7Z010 | |
| Production Picture |  |
 |
 |
 |
 |
 |
 |
 |
| Production Link | https://opensourcesdrlab.com/products/pluto-sdr-radio-ad9363-zynq7010 | https://opensourcesdrlab.com/products/pluto-plus?VariantsId=10313 | https://opensourcesdrlab.com/products/libresdr-zynqsdr-ad9363-zynq7020 | https://opensourcesdrlab.com/products/7010-ad9363-sdr-mini | https://opensourcesdrlab.com/products/new-7020-ad9363-plutosdr?VariantsId=10321 | https://opensourcesdrlab.com/products/new-7020-ad9363-plutosdr?VariantsId=10322 | https://opensourcesdrlab.com/products/geekrf-one-ad9363-zynq7020-plutosdr | https://opensourcesdrlab.com/products/opensourcesdrlab-pcie-version-plutosdr-ad9363-xc7z010?VariantsId=10329 |
| Frequency Range | 325MHz-3.8GHz (AD9363) 70MHZ~6GHZ (AD9361) AD9363 can be hacked to AD 9361 via software setting operation |
325MHz-3.8GHz (AD9363) 70MHZ~6GHZ (AD9361) AD9363 can be hacked to AD 9361 via software setting operation |
325MHz-3.8GHz (AD9363) 70MHZ~6GHZ (AD9361) AD9363 can be hacked to AD 9361 via software setting operation |
325MHz-3.8GHz (AD9363) 70MHZ~6GHZ (AD9361) AD9363 can be hacked to AD 9361 via software setting operation |
325MHz-3.8GHz (AD9363) 70MHZ~6GHZ (AD9361) AD9363 can be hacked to AD 9361 via software setting operation |
325MHz-3.8GHz (AD9363) 70MHZ~6GHZ (AD9361) AD9363 can be hacked to AD 9361 via software setting operation |
325MHz-3.8GHz (AD9363) 70MHZ~6GHZ (AD9361) AD9363 can be hacked to AD 9361 via software setting operation |
325MHz-3.8GHz (AD9363) 70MHZ~6GHZ (AD9361) AD9363 can be hacked to AD 9361 via software setting operation |
| RF Bandwidth | 200KHz-20MHz (AD9363) 200KHz-56MHz (AD9361) |
200KHz-20MHz (AD9363) 200KHz-56MHz (AD9361) |
200KHz-20MHz (AD9363) 200KHz-56MHz (AD9361) |
200KHz-20MHz (AD9363) 200KHz-56MHz (AD9361) |
200KHz-20MHz (AD9363) 200KHz-56MHz (AD9361) |
200KHz-20MHz (AD9363) 200KHz-56MHz (AD9361) |
200KHz-20MHz (AD9363) 200KHz-56MHz (AD9361) |
200KHz-20MHz (AD9363) 200KHz-56MHz (AD9361) |
| Sample Depth | 12 bits | 12 bits | 12 bits | 12 bits | 12 bits | 12 bits | 12 bits | 12 bits |
| Sample Rate | 20MSPS (AD9363) 56MSPS (AD9361) |
20MSPS (AD9363) 56MSPS (AD9361) |
20MSPS (AD9363) 56MSPS (AD9361) |
20MSPS (AD9363) 56MSPS (AD9361) |
20MSPS (AD9363) 56MSPS (AD9361) |
20MSPS (AD9363) 56MSPS (AD9361) |
20MSPS (AD9363) 56MSPS (AD9361) |
20MSPS (AD9363) 56MSPS (AD9361) |
| Transmitter Channels | 1 | 2 | 2 | 1 | 2 | 2 | 2 | 2 |
| Receivers | 1 | 2 | 2 | 1 | 2 | 2 | 2 | 2 |
| Duplex | Full | Full | Full | Full | Full | Full | Full | Full |
| Interface | Micro USB 2.0 | Micro USB 2.0 | Type C USB 2.0 | Type C USB 2.0 | Type C USB 2.0 | Type C USB 2.0 | Type C USB 2.0 | Type C USB 2.0 |
| Programmable Logic Cells | 28k | 28k | 85k | 28k | 85k | 85k | 28k | 28k |
| Chipset | AD9363 Xilinx ZYNQ 7010 |
AD9363 Xilinx ZYNQ 7010 |
AD9363 Xilinx ZYNQ XC7Z020 |
AD9363 Xilinx ZYNQ XC7Z010 |
AD9363 Xilinx ZYNQ 7020 |
AD9363 Xilinx ZYNQ 7020 |
AD9363 Xilinx ZYNQ 7010 |
AD9363 Xilinx ZYNQ 7010 |
| Open Source | Schematic, Firmware | Schematic, Firmware | Schematic, Firmware | Schematic, Firmware | Schematic, Firmware | Schematic, Firmware | Schematic, Firmware | Schematic, Firmware |
| Oscillator Precision | +/-0.5ppm | +/-0.5ppm | +/-0.5ppm | +/-0.5ppm | +/-0.5ppm | +/-0.5ppm | +/-0.5ppm | +/-0.5ppm |
| PCIE connector | no | no | no | no | no | no | no | yes |
