1. Frequency range and tuning step
Long wave (LW) 153-513kHz Step 9kHz, fine step 1kHz
Medium wave (MW) 520-1710kHz step 10kHz, fine tuning step 1kHz (applicable to America)
522-1620kHz step 9kHz, fine tuning step 1kHz (applicable to Asia, Africa, Europe and Oceania)
Short wave (SW) 1711-2999kHz Step by step 5kHz, fine adjustment step by step 1kHz
Frequency modulation (FM) 64-108MHz is applicable to Russia, the Caucasus and some Caspian and Black Sea regions
76-108MHz for Japan
87-108MHz is applicable to China and some European countries
88-108MHz is applicable to some countries in Europe and Australia
The frequency step of frequency modulation is 100kHz, and the fine adjustment step is 10kHz
2. Noise limiting sensitivity
Long wave (S/N=26dB)<10mV/m
Medium wave (S/N=26dB) 1mV/m
Short wave (S/N=26dB)<20uV
Frequency modulation (S/N=30dB)<3 μ V
3. Selectivity
Long wave>60dB
Medium wave>60dB
Short wave 60dB
FM>60dB
4. Intermediate frequency (DSP) amplitude modulation 45kHz; Frequency modulation 128kHz
5. Stored frequency address (excluding ETM)
Long wave 100
150 medium wave
Short wave 300
Frequency modulation 100
6. FM stereo separation ≥ 35dB
7. The maximum output power is about 200mW
8. Quiescent current
Long wave/medium wave/FM<25mA
Short wave<45mA
9. Shutdown current 90 μ A
10. Speaker 8 Ω, 0.25W
11 Stereo headphone impedance 32-150 Ω
12. Power supply 3.7V (one BL-5C lithium battery)
External DC power MicroUSB 5V current ≥ 500mA
13. Charger/power adapter USB DC 5V current ≥ 500mA (purchased separately)
14. Physical size 139 * 85 * 26 (mm)
15. Net weight is about 210g, without lithium battery
16. Accessories BL-5C lithium battery, stereo headset, USBMicroTypeC charging cable, protective sleeve, manual
