Application:
The amplifier features wide frequency range, high gain, and small noise figure. It can be used in various RF receiving front-ends to increase communication distance. Widely used in shortwave, FM broadcasting, remote control receiver, cable TV signal amplifier and other places where low noise and small signal RF amplification is needed.
Technical Parameters:
- Working Frequency: 2K-3000MHz
- Maximum Output Power: + 10dBm (10mW) @ 1dB compression point
- Noise Figure: 1.9dB (refer to the main view picture)
- Power Supply Voltage: 9-15VDC
- System Impedance: 50 ohms
Amplifier Gain (as shown in the figure below):
- F = 0.1MHz, gain = 32dB;
- F = 500Mhz, gain = 31dB;
- F = 1000MHz, gain = 29dB;
- F = 1500Mhz, gain = 25dB;
- F = 2000MHz, gain = 20dB
Package Included:
- 1 x Low Noise Amplifier
